LINLIFT - Professional custom material handling equipment manufacturer since 2002.
Crane Scale OCS-D6 - High Precision Load Measurement Tool
Features
● High quality alloy steel load components
● All steel chrome plated chassis
● High intensity activity type rings
● High strength type eye hook
● Change the type of rechargeable batteries
● A variety of display instrument selection
● LCD screen pen
● Back light
● Rechargeable batteries Mini dot matrix printer
● Display in both English and Chinese Size: 240x180x40cm
● Series specifications: 1000kg to 50000kg
Accuracy class | O I M L Ⅲ | Tare range | 100%F.S |
Zero range | 4%F.S | Safe load | 120%F.S |
Limit load | 400%F.S | Overload alarm | 100%F.S.+9e |
The battery specification | 6V/4Ah | Radio frequency | >450MHz |
The data transmission distance | ≥200m | Temperature range | -10℃~40℃ |
Model | (T) | A(mm) | C(mm) | D(mm) | E(mm) | H(mm) | kg | Pack size |
D6 | 1 | 94 | 27 | 270 | 140 | 590 | 13.2 | 42.5x40.5x40 |
2 | 94 | 35 | 270 | 140 | 600 | 13.5 | 42.5x40.5x40 | |
3 | 94 | 37 | 270 | 140 | 625 | 13.8 | 42.5x40.5x40 | |
5 | 120 | 45 | 270 | 140 | 650 | 22.6 | 42.5x40.5x40 | |
10 | 120 | 55 | 270 | 143 | 695 | 24.5 | 42.5x40.5x40 | |
15 | 110 | 62 | 295 | 180 | 730 | 40 | 80x40x40 | |
20 | 145 | 88 | 300 | 180 | 900 | 57.5 | 80×40x40 | |
30 | 155 | 100 | 300 | 180 | 1050 | 100 | 80x40x40 | |
50 | 210 | 185 | 300 | 200 | 1380 | 302 |
|
Size
