Crane Scale OCS-H04 for Heavy Loads - Accurate Weight Measurement
Features
● Preset tare weight / total accumulated qing accumulated value query
● Precision die-casting aluminum chassis
● Stainless steel rings
● Rotary hook
● Waterproof model panel buttons
● Infrared remote control
● Dividing value of switching
● Shake resistance setting
Accuracy class | 이ML III | Tare range | 100%F.S |
Zero range | 4%F.S | Safe load | 120%F.S |
Limit load | 300%F.S | Overload alarm | 100%F.S.+9e |
The battery specification | 6V/3.2Ah | Continuous working time | >60h |
The charger specification | 7.5V/1000mA | The remote control distance | 210m |
Temperature range | -10°C 〜40°C |
|
|
Model | (T) | A(mm) | B(mm) | C(mm) | D(mm) | E(mm) | H(mm) | kg | Pack size |
H04 | 0.3 | 50 | 172 | 27 | 230 | 140 | 370 | 5 | 42x26x20 |
0.5 | 50 | 172 | 27 | 230 | 140 | 370 | 5 | 42x26x20 | |
1 | 50 | 172 | 27 | 230 | 140 | 370 | 5 | 42x26x20 | |
2 | 55 | 172 | 37 | 230 | 140 | 455 | 8.2 | 42x26x20 | |
3 | 55 | 172 | 37 | 230 | 140 | 455 | 8.2 | 61x27.5x21.5 | |
5 | 55 | 172 | 45 | 230 | 140 | 670 | 12.6 | 71x34x31 |
Size
